BESS.EGV
The REMBE® explosion vent BESS.EGV offers optimum protection for your Battery Energy Storage Systems (BESS). BESS.EGV is available in a range of geometries with customizable burst pressures.
deflagration venting
as the most economical
solution.
Application
BESS.EGV is suitable for use in a wide range of BESS applications where roof installation is preferred. The standard burst pressure is 0.1 bar at 22 °C (71.6°F), but can be modified to suit any BESS design, as low as 0.025 bar.
Mechanism
When pressure rises during a deflagration, the vent opens at the defined breaking point and releases pressure from the BESS into the surrounding area.
Product parameters
| Standard burst pressure Pstat | 25-500 mbar |
| Max. permitted operating pressure | 50 % of Pstat |
| Temperature | – 40 to + 180 °C (– 40 to + 356 °F) |
| Material | Stainless steel |
| Gasket material | FDA approved silicon gasket |
| Tolerance | ± 20 % at standard burst pressure |
| Recommended torque for M10 screws | 20 Nm |
Our specialists will be pleased to assist you in finding a solution that matches your specific operating conditions.
Meets the requirements of NFPA 68
ATEX EC type examination certificate no. FSA 04 ATEX 1538 X
SIL-Equivalent SIL 4
Recommended Software
VENT.iNG. | Calculations according to EN + NFPA.
