VENTEX® Valve
VENTEX® valves are often used when explosion-proof decoupling of pressurized containers is required or air supply openings have to be secured effectively against flame and pressure discharge. The decades-old proven design offers you an effective, passive explosion safety solution. These valves can be controlled with or without external energy and offer simple and reliable explosion safety due to their extremely low response pressure and ease of maintenance.
isolation
valve.
Application
VENTEX® can be used in plants that process combustible dusts (incl. metal dusts), gases or hybrid mixtures. Common application areas include the pharmaceutical industry, chemical/petrochemical companies and research laboratories.
Mechanism
Without air flow, the closing body is in the open position. In normal operation, the air flows around the open poppet within the valve body. In the event of an explosion, the pressure wave forces the sealing poppet closed against the closing-body gasket. The valve locks, effectively preventing the spread of flames and pressure waves.
VENTEX® – Passive Explosion Isolation.
- Low response pressure.
- Short mounting distance.
- Used for Dust and/or Gas explosion (Incl. metal dust + hybrid mixtures).
- Passive closing principle.
- Bi-directional isolation in horizontal or vertical orientation.
Product Parameters
| Type | passive action: completely without control, sensors and external energy |
| Size | DN 100 – DN 600 |
| Pressure | for low, medium or high pressure: minimal pressure drop in the pipe |
| Dust load | for low dust load, maximum 50g/m3 |
| Medium | suitable for all common media: metallic dusts, hybrid mixtures, gases and organic dusts |
| Flow velocity | for low flow velocity, maximum 25m/s |
| Prozess temperature | for low, medium or high process temperatures |
| Mode of operation | available as single acting (ESI-E) or double acting (ESI-D), or as a check valve (ESI-C) |
| Installation position | vertical or horizontal installation |
- animal feed productions
- aspiration plants
- brewery
- chemical industry
- chemical- petrochemical
- filters
- food
- food production
- mills and grinding plantsmix
- mixers
- pharmaceutical industry
- recycling
- wood processing
Certified in accordance with EN 15089
ATEX EC type examination certificate no. FSA 21 ATEX 1708 X
